2504 DVJ WHISPAIR Vacuum Blower
The 2504 DVJ WHISPAIR™ vacuum blower is engineered for compact, high-performance vacuum applications, featuring an integrated cooling design and precision components to support reliable operation at deeper vacuum levels.
View Details
Product Specifications
This Whispair dry vacuum blower is built to deliver deep vacuum performance while maintaining operational stability. The unit incorporates a WHISPAIR™ design, featuring an integrated cooling design and precision components, to support airflow efficiency and improved thermal management at deeper vacuum levels.
Frame Size 2504 DVJ
Flow: Up to 3650 ICFM (6205 mÂł/hr)
Vacuum: Up to 28 INHgV (950 mbar)
Flow Range: Up to 145 CFM
Maximum Vacuum: 20" Hg
Maximum RPM: 4970
Minimum RPM: 1387
Maximum Temperature Rise (ΔT): 250°F
Inlet: 2.5" NPT
Discharge: 2.5" NPT
Jet Port: 2" NPT
Shaft Diameter: 0.75"
Drive End Lubrication: Grease
Gear End Lubrication: Oil
Horizontal Configuration: 6.625 oz
Vertical Configuration: 8.5 oz
Unit Weight: 65 lbs (29.55 kg)
Shipping: Skid-mounted
- Ball bearing configuration for smooth and reliable operation
- Lip-type seals to maintain lubrication control
- Splash lubrication at the gear end for consistent oil distribution
- Grease lubrication at the drive end for simplified maintenance
- WHISPAIR™ airflow design for improved efficiency and reduced thermal stress
- Configurable for horizontal or vertical installation
